Combo2 Charging Systems(CCS2)
Features
Charging plug meeting 62196-3 IEC SHEET 3-lm standard
Housing massive structure promote protection performance
Product entire insertion and extraction force<100N
Protection class IP55
Mechanical properties
Mechanical life: no-load plug in/pull out>10000 times
Impact of external force: can afford 1M drop and 2t vehicle run over pressure
Environment performance
Operating temperature: -30°C-+50°C
Applied Materials
Case Material: Thermoplastic, flame retardant grade UL94V-0
Contact bush: Copper alloy,silver plating
Electrical performance
Rated current: 200A
Operation voltage: 1000V DC
Insulation resistance:>500MΩ(D1000V)
Terminal temperature rise: <50K
Withstand temperature rise: <50K
Withstand Voltage: 3000V
EV Charging Cable CCS2 Features
- Conform to the provisions and requirements of IEC62196-2 2016 2-llb, it can charge all EV manufactured in Europe and USA, correctly and effectively with high compatibility.
- Using riveting pressure process with none screw with beautiful appearance. Hand-held design conform to ergonomic principle, plug conveniently.
- XLPO for cable insulation prolonging the aging resistance life-span. TPU sheath improves the bending life and wear resistance of cable. The best material in the market at present, conforms to the latest European Union standards.
- Excellent internal waterproof protection performance, protection grade achieved IP55 (working condition). The shell can effectively insulate water from body and enhance the safety level even in bad weather or special circumstances.
- Adopted double color coating technology, customized color accepted (regular color orange, blue, green, grey, white)
- Keep the laser logo space for customer. Provide OEM/ODM service to help customer expand market easier
EV Charging Cable CCS2 Parameter
|
Product Type |
CCS2 EV Charging Cable |
|
Rated Current |
80A, 125A, 150A, 200A, 250A, 300A |
|
Rated Voltage |
1000V |
|
Cable Specification |
2*15mm²+1*25mm²+(6*0.75mm²) (P2) |
|
2*35mm²+1*25mm²+(6*0.75mm²) (P2) |
|
|
2*50mm²+1*25mm²+(6*0.75mm²) (P2) |
|
|
2*70mm²+1*25mm²+(6*0.75mm²) (P2) |
|
|
2*80mm²+1*25mm²+(6*0.75mm²) (P2) 2*95mm²+1*25mm²+(6*0.75mm²) (P2) |
|
|
Length |
Regular 5 m, customized length accepted |
|
Color |
black, customized color accepted |
|
Warranty |
12 months |
|
Certificate |
CE/TUV Rheinland |
|
Packaging Details |
Standard export wooden case or carton. Or as customer requirements |
|
Delivery Time (days) |
Within 15days, if quantity >100, to be negotiated |
CCS Combo 2 Plug 80A: An efficient tool for charging electric vehicles
CCS (Combined Charging System) Combo 2 plug is a connector designed for modern electric vehicle charging with excellent performance and flexibility.
Rated current: 80A
It supports currents up to 80 amps, which means it can provide a large amount of power to electric vehicles in a short period of time, speeding up charging.
Operating voltage: DC 1000V
The operating voltage of this connector is 1000 volts DC, which is sufficient to meet the charging needs of various electric vehicles, including high-end electric vehicles.
Insulation resistance: >1000MΩ (DC500V)
The insulation resistance exceeds 1000 megohms (at 500 volts DC), ensuring the safety and reliability of the charging process.
Maximum DC charging power: 127.5 kW
This feature enables it to support high-power DC fast charging, allowing electric vehicles to be fully charged in a short time and extending their driving range.
Maximum AC charging power: 41.5 kW
It not only supports DC charging, but also meets the needs of AC charging, and is suitable for various charging equipment and occasions.
Voltage resistance: 3200 volts
The voltage withstand capability reaches 3200 volts, indicating that it can withstand voltage shocks, ensuring the safety of users and the reliability of equipment.
These features make the CCS Combo 2 Plug 80A an integral part of modern electric vehicle charging stations. It is widely used in fast charging stations, transportation hubs, commercial buildings and public charging points, providing electric vehicle owners with efficient and convenient charging solutions.
|
Features |
1. Meet 62196-3 IEC 2011 SHEET 3-Im standard |
||
|
2. Concise appearance, support back installation |
|||
|
3. Back Protection class IP55 |
|||
|
4. Max charging power: 127.5kW |
|||
|
5. AC Max charging power: 41.5kW |
|||
|
Mechanical Properties |
1. Mechanical life: no-load plug in/pull out＞10000 times |
||
|
2. Impat of external force: can afford 1m drop amd 2t vehicle run over pressure |
|||
|
Electrical Performance |
1. DC input: 80A, 125A, 150A, 200A 1000V DC MAX |
||
|
2. AC input: 16A 32A 63A 240/415V AC MAX |
|||
|
3. Insulation resistance: ＞2000MΩ(DC1000V) |
|||
|
4. Terminal temperature rise: ＜50K |
|||
|
5. Withstand Voltage: 3200V |
|||
|
6. Contact resistance: 0.5mΩ Max |
|||
|
Applied Materials |
1. Case Material: Thermoplastic, flame retardant grade UL94 V-0 |
||
|
2. Pin: Copper alloy, silver +thermoplastic on the top |
|||
|
Environmental Performance |
1. Operating temperature: -30°C~+50°C |
||
|
Model selection and the standard wiring |
|||
|
Model |
Rated Current |
Cable Specigication |
Cable Color |
|
AP-CSS2-EV150P |
150A |
2 X 50mm²+1 X 25mm² +6 X 0.75mm² |
Orange or Black |
